Other Sinamics (33)

6SL3544-0NB02-1PA0

SINAMICS G110M Control Unit CU240M DP G PROFIBUS DP with M screw connection 4 DI, 2 DO, 2 AI, 1 F-DI PTC/KTY connection EM brake control Degree of protection IP66 Ambient temperature -10 to +55 C 105x 171x 205 (HxWxD) without Power Module

Detalii

6SL3544-0PB02-1FA0

SINAMICS G110M Control Unit CU240M PN Q PROFINET with plug-in connections 4 DI, 2 DO, 2 AI, 1 F-DI PTC/KTY connection EM brake control Degree of protection IP65 Ambient temperature -10 to +55 C 105x 171x 216 (HxWxD) without Power Module

Detalii

6SL3544-0PB02-1MA0

SINAMICS G110M Control Unit CU240M AS-Interface Q AS-Interface with plug-in connections for motor frame size 80/90 4 DI, 2 DO, 2 AI, 1 F-DI PTC/KTY connection EM brake control Degree of protection IP65 Ambient temperature -10 to +55 105x 205x 171 (HxWxD) without Power Module

Detalii

6SL3544-0PB02-1PA0

SINAMICS G110M Control Unit CU240M DP Q PROFIBUS DP with plug-in connections 4 DI, 2 DO, 2 AI, 1 F-DI PTC/KTY connection EM brake control Degree of protection IP65 Ambient temperature -10 to +55 C 105x 171x 216 (HxWxD) without Power Module

Detalii

6SL3544-0QB02-1FA0

SINAMICS G110M Control Unit CU240M PN Q PROFINET with plug-in connections 4 DI, 2 DO, 2 AI, 1 F-DI PTC/KTY connection EM brake control Degree of protection IP65 Ambient temperature -10 to +55 C 105x 171x 216 (HxWxD) without Power Module

Detalii

6SL3544-0QB02-1MA0

SINAMICS G110M Control Unit CU240M AS-Interface Q AS-Interface with plug-in connections for motor frame size 100/112 4 DI, 2 DO, 2 AI, 1 F-DI PTC/KTY connection EM brake control Degree of protection IP65 Ambient temperature -10 to +55 105x 205x 171 (HxWxD) without Power Module

Detalii

6SL3544-0QB02-1PA0

SINAMICS G110M Control Unit CU240M DP Q PROFIBUS DP with plug-in connections 4 DI, 2 DO, 2 AI, 1 F-DI PTC/KTY connection EM brake control Degree of protection IP65 Ambient temperature -10 to +55 C 105x 171x 216 (HxWxD) without Power Module

Detalii

6SL3544-0TB02-1FA0

SINAMICS G110M Control Unit CU240M PN Q PROFINET with plug-in connections 4 DI, 2 DO, 2 AI, 1 F-DI PTC/KTY connection EM brake control Degree of protection IP65 Ambient temperature -10 to +55 C 105x 171x 216 (HxWxD) without Power Module

Detalii

6SL3544-0TB02-1MA0

SINAMICS G110M Control Unit CU240M AS-Interface Q AS-Interface with plug-in connections for motor frame size 71 4 DI, 2 DO, 2 AI, 1 F-DI PTC/KTY connection EM brake control Degree of protection IP65 Ambient temperature -10 to +55 105x 205x 171 (HxWxD) without Power Module

Detalii

6SL3544-0TB02-1PA0

SINAMICS G110M Control Unit CU240M DP Q PROFIBUS DP with plug-in connections 4 DI, 2 DO, 2 AI, 1 F-DI PTC/KTY connection EM brake control Degree of protection IP65 Ambient temperature -10 to +55 C 105x 171x 216 (HxWxD) without Power Module

Detalii

6SL3546-0FB21-1FA0

SINAMICS G120D Control Unit CU250D-2 PN-F PROFINET and Safety Integrated with positioning capability (EPOS) 6 DI/3 F-DI, 2 DO/1 F-DO, 2 AI USB interface SD/MMC card interface HTL and SSI encoder interface Degree of protection IP65 Ambient temperature -10 to +50 C without Power Module

Detalii

6SL3546-0FB21-1FB0

SINAMICS G120D Control Unit CU250D-2 PN-F PP PROFINET and Safety Integrated with positioning capability (EPOS) in push-pull version 6 DI/3 F-DI, 2 DO/1 F-DO, 2 AI SD/MMC card interface HTL and SSI encoder interface Degree of protection IP65 Ambient temperature 0 to +50 C without Power Module

Detalii

6SL3546-0FB21-1FC0

SINAMICS G120D Control Unit CU250D-2 PN-F FO PPROFINET via fiber-optic cable and Safety Integrated in push-pull version with positioning capability (EPOS) 6 DI/3 F-DI, 2 DO/1 F-DO HTL and SSI encoder interface Degree of protection IP65 Ambient temperature 0 to +45 C without Power Module

Detalii

6SL3546-0FB21-1PA0

SINAMICS G120D Control Unit CU250D-2 DP-F PROFIBUS and Safety Integrated with positioning capability (EPOS) 6 DI/3 F-DI, 2 DO/1 F-DO, 2 AI USB interface SD/MMC card interface HTL and SSI encoder interface Degree of protection IP65 Ambient temperature 0 to +55 C without Power Module

Detalii
