> >>>Other SIPLUS

Other SIPLUS

  • SIPLUS S7-1200 CM1241 with conformal coating based on 6ES7241-1CH32-0XB0 . Communication module CM 1241, RS422/485, 9-pole D-sub (pin) supports Freeport

    Detalii

  • SIPLUS NET CSM 1277 with conformal coating based on 6GK7277-1AA10-0AA0 . Compact Switch Module CSM 1277 Connection SIMATIC S7-1200 and up to 3 further nodes to Industrial Ethernet with 10/100 Mbit/s

    Detalii

  • SIPLUS S7-1200 SM 1278 IO-Link with conformal coating based on 6ES7278-4BD32-0XB0 . Signal module SM 1278 4xIO-Link Master IO-Link Master V1.1

    Detalii

  • SIPLUS S7-300 PS 307 -25 ... +70 DGR C WITH CONFORMAL COATING BASED ON 6ES7307-1EA01-0AA0 . STABILIZED POWER SUPPLY INPUT: 120/230 V AC OUTPUT: 24 V DC/5 A.

    Detalii

  • SIPLUS S7-300 CPU 312C with conformal coating according to EN 50155 T1 Cat 1 Cl A/ B based on 6ES7312-5BF04-0AB0 . Compact CPU with MPI, 10 DI/6 DQ, 2 high-speed counters (10 kHz) Integr. power supply 24 V DC, work memory 64 KB, Front connector (1x 40-pole) and Micro Memory Card required

    Detalii

  • SIPLUS S7-300 CPU 313C with conformal coating according to EN 50155 T1 Cat 1 Cl A/ B based on 6ES7313-5BG04-0AB0 . Compact CPU with MPI, 24 DI/16 DO, 4 AI, 2 AO, 1 Pt100, 3 high-speed counters (30 kHz), Integr. power supply 24 V DC, work memory 128 KB, Front connector (2x 40-pole) and Micro Memory Card required

    Detalii

  • SIPLUS S7-300 CPU CPU 313C-2DP with conformal coating according to EN 50155 T1 Cat 1 Cl A/ B based on 6ES7313-6CG04-0AB0 . Compact CPU with MPI, 16 DI/16 DO, 3 high-speed counters (30 kHz), integrated DP interface, Integr. power supply 24 V DC, work memory 128 KB, Front connector (1x 40-pole) and Micro Memory Card required

    Detalii

  • SIPLUS S7-300 CPU 314C-2DP with conformal coating according to EN 50155 T1 Cat 1 Cl A/ B based on 6ES7314-6CH04-0AB0 . Compact CPU with MPI, 24 DI/16 DO, 4 AI, 2 AO, 1 Pt100, 4 high-speed counters (60 kHz), integrated DP interface, Integr. power supply 24 V DC, work memory 192 KB, Front connector (2x 40-pole) and Micro Memory Card required

    Detalii

  • SIPLUS S7-300 CPU 315-2DP -25 ... +60 DEGREES C WITH CONFORMAL COATING ACCORDING EN50155 T1 KAT 1 KL A BASED ON 6ES7315-2AH14-0AB0 . CPU WITH MPI INTERFACE INTEGRATED 24 V DC POWER SUPPLY 256 KBYTE WORKING MEMORY 2. INTERFACE DP-MASTER/SLAVE MICRO MEMORY CARD NECESSARY

    Detalii

  • SIPLUS S7-300 CPU315-2PN/DP -25 ... +70 DEGREES C WITH CONFORMAL COATING BASED ON 6ES7315-2EH14-0AB0 . CENTRAL PROCESSING UNIT WITH 384 KBYTE WORKING MEMORY, 1. INTERFACE MPI/DP 12MBIT/S, 2. INTERFACE ETHERNET PROFINET, WITH 2 PORT SWITCH, MICRO MEMORY CARD NECESSARY

    Detalii

  • SIPLUS S7-300 CPU 315F-2PN/DP Conformity with EN 50155 T1 Kat 1 Kl A/B with conformal coating based on 6ES7315-2FJ14-0AB0 . Central processing unit with 512 KB work memory, 1st interface MPI/DP 12Mbit/ s, 2nd interface Ethernet PROFINET, with 2-port switch, Micro Memory Card required

    Detalii

  • SIPLUS S7-300 CPU 315F-2DP with conformal coating according to EN 50155 T1 Cat 1 Cl A/ B based on 6ES7315-6FF04-0ab0 . Fail-safe module with MPI Integr. power supply 24 V DC, Work memory 384 KB, 40 mm width, 2nd interface DP master/ slave Micro Memory Card required

    Detalii

  • SIPLUS S7-300 CPU 317F-2PN/DP conformity with EN 50155 T1 Kat 1 Kl A/B Based on 6ES7317-2FK14-0AB0 . Central processing unit with 1.5 MB work memory, 1st interface MPI/DP 12Mbit/ s, 2nd interface Ethernet PROFINET, with 2-port switch, Micro Memory Card required

    Detalii

  • SIPLUS S7-300 SM321 - 20-POLE -40 ... +70 DGR C WITH CONFORMAL COATING CONFORMITY WITH EN50155 T1 KAT 1 KL A/B BASED ON 6ES7321-1BH02-0AA0 . DIGITAL INPUT OPTIC. ISOLATED 16 DI, 24V DC, 1 X 20-POLE

    Detalii

  • SIPLUS S7-300 SM321 - 40-POLE -40 ... +70 DGR C WITH CONFORMAL COATING CONFORMITY TO EN50155 T1 CAT 1 CL A/B BASED ON 6ES7321-1BL00-0AA0 . DIGITAL INPUT OPTICALLY ISOLATE 32DI, 24 V DC, 1 X 40 PIN

    Detalii

  • SIPLUS S7-300 SM 321 16DI 0-1 threshold at approx. 11.2 V with conformal coating based on 6ES7321-7BH01-0AB0 . Digital input SM 321, isolated, 16 DI; 24 V DC, 1x 20-pole, process interrupt, diagnostics, suitable for isochronous mode operation

    Detalii

  • SIPLUS S7-300 SM 321 4DI NAMUR for medial exposure with conformal coating based on 6ES7321-7RD00-0AB0 . Digital input Isolated 4 DI; 24 V DC, NAMUR/DIN 19234, for signals from the hazardous area, diagnostics-capable, PTB tested

    Detalii

  • SIPLUS PCS 7 SM 321 16DI for medial exposure with conformal coating based on 6ES7321-7TH00-0AB0 . Digital input 16 DI; 24 V DC, 1x 40-pole, diagnostics-capable, for contacts (wired/ not wired), NAMUR encoder, 3/4-wire BERO, with chatter monitoring; Pulse extension, Open-circuit detection Connection IM 153-2 required

    Detalii

  • SIPLUS S7-300 SM322 - 20-POLE -25...+70 DGR C WITH CONFORMAL COATING WITH CONFORMITY EN50155 T1 CAT 1 KL A/B BASED ON 6ES7322-1BH01-0AA0 . DIGITAL OUTPUT OPTIC. ISOLATED 16D0, 24V DC, 0.5A, SUM OF CURRENTS 4A/GROUP (8A/MODULE)

    Detalii

  • SIPLUS S7-300 SM322 32 DO - 40-POLE -25 ... +70 DGR C WITH CONFORMAL COATING CONFORMITY WITH EN50155 T1 KAT 1 KL A/B BASED ON 6ES7322-1BL00-0AA0 . DIGITAL OUTPUT SM 322, OPTICALLY ISOLATED, 32DO, 24V DC, 0.5A, 1 X 40 PIN, SUM OF OUTPUT CURRENTS 4A/GROUP (16A/MODULE)

    Detalii
