6DR5023-0DG02-0AA0

SIPART PS2 smart electropneumatic positioner for pneumatic linear and part-turn actuators; 2-wire; 4...20mA; double action; Enclosure Aluminium . Type of protection (Ex): Increased safety (Ex e), Dust ignition protection by enclosure (Ex t) Connection thread el.: M20x1.5 / pneu.: G 1/4 Without Analog Input Module (AIM) to connect external position detection systems, e.g. NCS Sensor, Position Transmitter 6DR4004-1ES/2ES/3ES/4ES or other sensors. The internal position detection via a potentiometer is not applied but can be ordered in addition with ?Z K11. Device plug M12 optionally orderable with -Z D54. . Brief instructions German / English / Chinese Standard / Fail-Safe - Depressurizing the actuator in case of failure of electrical auxiliary power without mounted pressure gauge block
